PCB manufacturing & assembly capabilities
Your boards are built at vetted partner factories in China. The figures below come from the production lines I work with; exact limits for your design are confirmed during the free DFM check.
PCB fabrication
| Item | Partner factory capability |
|---|---|
| Board types | Single-sided, double-sided and multilayer PCBs; prototypes and volume production |
| Layer count | Multilayer production demonstrated to 8 layers (e.g. 4 mil traces, 0.25 mm min. hole) |
| Min. line width / spacing | 3/3 mil (fine-line work with fully automatic LDI imaging) |
| Min. hole (demonstrated) | 0.25 mm (on the 8-layer example above) |
| Plating aspect ratio | 8:1 (automatic horizontal pattern-plating line) |
| Surface finishes | Immersion gold (ENIG), HASL, OSP (anti-oxidation), gold fingers |
| Solder mask colours | Green, blue, red, white, black |
| Typical lead time | Double-sided: 4–8 days · Multilayer: 6–12 days (confirmed on each quote) |
| Inspection & test | 100% AOI, flying-probe and automated electrical test, final quality control (FQC) |
| Partner line certifications | ISO 9001, ISO 14001, UL, IATF 16949 |
Need something not listed here, such as controlled impedance, HDI / blind & buried vias, flex or rigid-flex, aluminium / metal-core or high-frequency materials? Ask with your files. I will only confirm what a partner factory can actually build for your design.
PCB assembly (PCBA)
Assembly capabilities depend on the assembly partner matched to your job and are confirmed per quote.
SMT & through-hole
Surface-mount and through-hole assembly, including post-soldering of connectors and odd-form parts.
Turnkey or consigned
I source all parts, or you ship your own parts or a partial kit. The BOM is checked either way.
Inspection
Bare-board AOI and electrical test, then assembly inspection. Functional testing is possible to your test procedure.
Photos from my own order records.
Files for an accurate quote
- Gerber RS-274X (zip) including drill files, or your Altium/KiCad project
- Stack-up, board thickness, copper weight, finish and mask colour (if specified)
- For PCBA: BOM (xlsx/csv) with manufacturer part numbers, plus pick-and-place / centroid file
- No production files yet? Send your design project or schematic and I'll prepare them (see production files)
Not sure what's needed?
Send what you have. Missing information shows up in the DFM check and I'll ask for it.
Have a PCB or PCBA job? Hand me any part of it, or all of it.
Send your Gerber and BOM, or whatever you have so far. I check it for manufacturability and reply by e-mail with questions and a free quote.
